PSF0716. Portable / wall-mounted 1-phase AC electric vehicle charger. Suitable for US; EU; JP; UK and other international electrical standards AC240V± 15%; 16A; 3.5kW household type 2 electric vehicle intelligent charging station.
technical parameter:
Input rating: 240V ± 15%;
Output rating: 0-16A;3.5kw
Rated frequency: 50 / 60 Hz;
Power Wiring: 3wire-live ; neutral plus PE ；
Connector type: IEC 62196-2 / SAE J1772;
Charig control: APP; RFID Card; Button;
Ocpp Protocol (optional): 1.6 or 2.0.1;
External Communication: LAN(RJ-45) and WIFI ；
Storage Temperature: -40 to 75ºC (-40 to 167ºF) ambient
Operating Temperature: -30 to 55ºC (-22 to 131ºF) ambient
Working life of connector machinery: 10000 times (no-load plugging);
Charging cable length: random standard standard 5m. Support to purchase 10m; 15m;
Quality assurance: 12 months;
Waterproof grade: IP65;
Product Certification: 3C; CE; ROHS; REACH.
Product features:
1. The APP control of the
△ Set the current: when the power grid is overloaded; you can set the current;
△ Control the stop and start: control the stop and start of your phone; you can control it anywhere;
△ Reservation charging: If you want an electric car to charge at night; booking charging through the APP is a good choice; very convenient;
△ Record: You can view the charge record through the APP at any time;
△ This is the best choice for you into the domestic market.
2. Load balance management:
△ Limit the total charging load can protect the local power grid;
△ Sharing the charging load can reduce the required cost of power connection;
△ Choose the open CT (current transformer) as the current sensor; and there is no physical wiring between the equipment; with the advantages of open and closed installation; convenient and fast wiring; and no additional infrastructure or installation cost.
3. Specifications
△ Material: the front panel is tempered glass; with the advantages of scratch prevention and high quality visual effect. The rear cover is made of high quality metal plate; special integral molding; suitable for indoor and outdoor safety.
△ OEM or ODM available: logo; brand; design; size; color; function; fault information; etc.; support for customization;
△ 3.5-inch highlight LCD screen: display real-time charging current; voltage; power consumption; time;
△ Multi-function installation wall installation or base application.
4. Protect
△ High quality; safe and reliable use of production design standards: overvoltage protection; overvoltage protection; overload protection; short circuit protection; leakage protection; grounding protection; over temperature protection; surge protection; etc.
Note: If the single product weight of DC / AC EV charger is more than 10 KG, both parties shall negotiate the quotation of transportation cost
